The ARMASPEC Stainless Steel TKDWN/Pivot Arm 147‑SS is a premium‑grade pivot arm designed for heavy‑duty industrial applications where strength, precision, and corrosion resistance are non‑negotiable. Constructed from 304-grade stainless steel, this pivot arm delivers unparalleled durability in harsh environments, making it the ideal choice for manufacturing, automation, and marine sectors.

Key Benefits

• Corrosion‑Resistant 304 Stainless Steel – Ideal for exposure to moisture, chemicals, and saline environments.
• Heavy‑Duty Load Capacity – Engineered to handle dynamic loads up to 150 kg (330 lb) with a safety factor of 3.
• Precision Pivot Design – Smooth 360° rotation with minimal play for accurate positioning.
• Easy Installation – Pre‑drilled mounting holes and a universal ½‑inch pivot shaft fit standard hardware.
• Low Maintenance – No need for additional protective coatings; stainless finish maintains performance over time.
• Versatile Compatibility – Works seamlessly with ARMASPEC TKDWN series, as well as third‑party pivot systems.

Technical Specifications

Typical Applications

The ARMASPEC 147‑SS pivot arm excels in the following settings:

• Automated assembly lines – precise component positioning.
• Marine equipment – corrosion‑resistant hinges for deck hardware.
• Food processing plants – sanitary, stainless steel hardware compliant with FDA standards.
• Robotics – high‑load pivot points for articulated arms.
• Heavy‑duty conveyors – reliable pivot support for moving sections.

Installation Guide

1. Verify the mounting surface is flat and free of debris.
2. Align the pre‑drilled holes on the arm with the corresponding holes on the base.
3. Insert stainless steel bolts (M6 recommended) and tighten to 8 Nm (70 in‑lb) torque.
4. Attach the ½‑inch pivot shaft, ensuring it rotates freely without binding.
5. Perform a functional test by moving the arm through its full range of motion.

Why Choose ARMASPEC?

ARMASPEC has a legacy of delivering high‑performance industrial hardware that meets the most demanding specifications. Our stainless steel pivot arms undergo rigorous testing for load endurance, corrosion resistance, and dimensional stability, ensuring you receive a product that performs reliably day after day.
