KGM A‑QDA‑DL Quick Det Adapter Dual Latch – Model DA111 (UPC 810042340350)

Introducing the KGM A‑QDA‑DL Quick Det Adapter Dual Latch, the premier solution for fast, secure connections in demanding environments. Engineered by KGM, this dual‑latch adapter (model DA111) delivers rapid detachment and re‑attachment without sacrificing mechanical strength or electrical integrity.

Key Benefits

• Rapid Installation: The innovative quick‑det mechanism reduces connection time by up to 50% compared with standard latching systems.
• Dual‑Latch Security: Two independent latch points provide redundant holding power, ensuring a fail‑safe connection even under vibration or shock.
• Robust Construction: Made from high‑grade, corrosion‑resistant alloy, the A‑QDA‑DL withstands harsh chemicals, extreme temperatures, and UV exposure.
• Universal Compatibility: Designed to interface seamlessly with KGM’s extensive connector family, making it ideal for retrofits and new builds.
• Compact Footprint: Low-profile design saves valuable space in tight enclosures while maintaining full performance.

Technical Specifications

• Model Number: A‑QDA‑DL (DA111)
• UPC: 810042340350
• Connector Type: Quick‑det dual latch
• Material: Premium zinc‑die‑cast alloy with nickel plating
• Operating Temperature Range: -40 °C to +125 °C
• Current Rating: Up to 10 A per contact
• Voltage Rating: 250 V AC/DC
• Contact Configuration: 2‑pole, 2‑throw (2P2T) with optional grounding pin
• IP Rating: IP67 (dust‑tight and water‑resistant)
• Mounting Style: Panel mount, front‑panel or rear‑panel
• Dimensions: 22 mm × 12 mm × 8 mm (L × W × H)
• Weight: 7 g

Ideal Applications

The KGM A‑QDA‑DL Quick Det Adapter Dual Latch is engineered for a wide range of industries, including:

• Industrial automation and control panels
• Automotive wiring harnesses and diagnostic tools
• Aerospace and avionics equipment
• Medical devices requiring reliable, quick‑connect interfaces
• Telecommunications racks and network infrastructure
• Robotics and IoT devices operating in rugged environments

Why Choose KGM?

With over three decades of expertise in connector technology, KGM delivers products that combine precision engineering with cost‑effective manufacturing. The A‑QDA‑DL series exemplifies KGM’s commitment to:

• High reliability and long service life
• Ease of maintenance and serviceability
• Compliance with international standards (IEC, ISO, RoHS)
• Responsive technical support and documentation

Installation & Maintenance Tips

1. Ensure the mating connector is clean and free of debris before engagement.
2. Align the pins carefully; the dual‑latch mechanism will lock automatically when fully seated.
3. To release, depress the release lever on both latch sides simultaneously for a smooth detachment.
4. Periodically inspect the latch springs for wear and replace if necessary to maintain optimal performance.
5. Store unused adapters in a dry environment to prevent corrosion.

Compliance & Certifications

The A‑QDA‑DL adapter meets the following certifications and standards:

• CE Marking – Conforms to EU safety, health, and environmental requirements
• UL Listed – Certified for use in North American applications
• RoHS Compliant – Free of hazardous substances above regulated limits
• ISO 9001:2015 – Quality management system

Ordering Information

When ordering, reference the exact model and UPC to avoid confusion:

• Product Name: KGM A‑QDA‑DL Quick Det Adapter Dual Latch
• Model: DA111
• UPC: 810042340350
• Packaging: 1‑piece bulk pack, optional anti‑static sleeve

For detailed datasheets, CAD files, or custom configuration requests, contact your KGM distributor or visit the official KGM website.
